| Artikelnummer | DLC0283FZG-7 |
| varumärke | Other |
| Storlek | 2.8 |
| Ansökan | MPH |
| Upplösning | 240×320 |
| Sammansättning | LCM |
| Ljusstyrka | 300 |
| CR | 400:1 |
| Färger | 262K |
| Bakgrundsbelysning | WLED |
| Gränssnitt | CPU/RGB |
| panelmärke | DLC |
| panelmodell | DLC0283FZG-7 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 2.8 inch |
| upplösning | 240(RGB)×320 , QVGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 43.2×57.6 mm |
| skissera | 50×70 mm |
| yta | |
| ljusstyrka | 300 cd/m² (Typ.) |
| Kontrastförhållande | 400:1 (Typ.) |
| visa färger | 262K , CIE193150% |
| respons tid | 25 (Typ.)(Tr+Td) |
| betraktningsvinkel | 60/60/60/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 5S1PWLEDWithout Driver |
| signalgränssnitt | CPU/RGB, 39 pins |
| inspänning | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| Ansökan | MPH |
