| Artikelnummer | CLAA133WA01A |
| varumärke | CPT |
| Storlek | 13.3 |
| Ansökan | NBPC |
| Upplösning | 1366×768 |
| Sammansättning | LCM |
| Ljusstyrka | 200 |
| CR | 600:1 |
| Färger | 262K |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | CPT |
| panelmodell | CLAA133WA01A 9 Compatible model |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 13.3 inch |
| upplösning | 1366(RGB)×768 , WXGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 293.417×164.966 mm |
| skissera | 314.1×188.75×3.6 mm |
| form stil | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| yta | Glare (Haze 0%), Hard coating (3H) |
| ljusstyrka | 200 cd/m² (Typ.) |
| Kontrastförhållande | 600:1 (Typ.) |
| visa färger | 262K (6-bit), CIE193145% |
| respons tid | 8 (Typ.)(Tr+Td) |
| betraktningsvinkel | 40/40/15/30 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | WLEDEmbedded (LED Driver) |
| signalgränssnitt | LVDS (1 ch, 6-bit), 40 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | NBPC |
| CLAA133UA01 | CPT | 13.3 | 1600×900 |
| CLAA133UA03 | CPT | 13.3 | 1600×900 |
| CLAA133WA01A | CPT | 13.3 | 1366×768 |
| CLAA133WB01A | CPT | 13.3 | 1366×768 |
| L5F30812P00 | Epson | 13.3 | 1024×768 |
| LP133WX2-TLA2 | LG Display | 13.3 | 1280×800 |
| LQ133T1JW01 | SHARP | 13.3 | 2560×1440 |
| LTD133EV2F | TOSHIBA | 13.3 | 1280×800 |
| LTN133HL01-301 | Samsung | 13.3 | 1920×1080 |
| N133BGE-EAB | Innolux | 13.3 | 1366×768 |
| B121EW09 V4 | AUO | 12.1 | 1280×800 |
| B140HTN01.3 | AUO | 14.0 | 1920×1080 |
| B156XTT01.1 | AUO | 15.6 | 1366×768 |
| LP141XA-A1 | LG Display | 14.1 | 1024×768 |
| LP150X09-A3K1 | LG Display | 15.0 | 1024×768 |
| LP154WX4-TLA1 | LG Display | 15.4 | 1280×800 |
| LT121S1-101 | Samsung | 12.1 | 800×600 |
| LTN121AT06-G01 | Samsung | 12.1 | 1280×800 |
| LTN140AT21-801 | Samsung | 14.0 | 1366×768 |
| N156BGE-LB1 | Innolux | 15.6 | 1366×768 |
