| Artikelnummer | CLAA133UA01 |
| varumärke | CPT |
| Storlek | 13.3 |
| Ansökan | NBPC |
| Upplösning | 1600×900 |
| Sammansättning | LCM |
| Ljusstyrka | 300 |
| CR | 500:1 |
| Färger | 262K |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | CPT |
| panelmodell | CLAA133UA01 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 13.3 inch |
| upplösning | 1600(RGB)×900 , HD+ |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 293.28×164.97 mm |
| skissera | 314.1×192.25×3.1 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| yta | Antiglare |
| ljusstyrka | 300 cd/m² (Typ.) |
| Kontrastförhållande | 500:1 (Typ.) |
| visa färger | 262K (6-bit), CIE193145% |
| respons tid | 6/10 (Typ.)(Tr/Td) |
| betraktningsvinkel | 40/40/15/30 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | WLEDEmbedded (LED Driver) |
| signalgränssnitt | LVDS (2 ch, 6-bit), 40 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | NBPC |
