| Artikelnummer | A101AIE40L0 |
| varumärke | Aptus |
| Storlek | 10.1 |
| Ansökan | IA |
| Upplösning | 1280×720 |
| Sammansättning | LCM |
| Ljusstyrka | 500 |
| CR | 1000:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | Aptus |
| panelmodell | A101AIE40L0 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 10.1 inch |
| upplösning | 1280(RGB)×720 , WXGA |
| visningsläge | AHVA, Normally Black, Transmissive |
| aktivt område | 223.68×125.82 mm |
| skissera | 238.6×148 mm |
| yta | |
| ljusstyrka | 500 cd/m² (Typ.) |
| Kontrastförhållande | 1000:1 (Typ.) |
| visa färger | 16.7M (6-bit + Hi-FRC) |
| respons tid | 40 (Max.)(Tr+Td) |
| betraktningsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 9S3PWLEDWithout Driver |
| signalgränssnitt | LVDS (1 ch, 8-bit), 40 pins |
| inspänning | 3.3/3.3V (Typ.)(VDD/AVDD) |
| Ansökan | IA |
