| Artikelnummer | TX14D22VM1BAA |
| varumärke | KOE |
| Storlek | 5.7 |
| Ansökan | IA |
| Upplösning | 320×240 |
| Sammansättning | LCM |
| Ljusstyrka | 400 |
| CR | 350:1 |
| Färger | 262K |
| Bakgrundsbelysning | WLED |
| Gränssnitt | TTL |
| panelmärke | HITACHI |
| panelmodell | TX14D22VM1BAA |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 5.7 inch |
| upplösning | 320(RGB)×240 , QVGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 115.2×86.4 mm |
| skissera | 131×102.2×7.1 mm |
| yta | |
| ljusstyrka | 400 cd/m² (Typ.) |
| Kontrastförhållande | 350:1 (Typ.) |
| visa färger | 262K (6-bit), CIE193150% |
| respons tid | 30 (Typ.)(Tr+Td) |
| betraktningsvinkel | 80/80/80/60 (Typ.)(CR≥5)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 3S5PWLEDWithout Driver |
| signalgränssnitt | CMOS (1 ch, 6-bit), 40 pins |
| inspänning | 3.3V (Typ.)(VDD) |
| Ansökan | IA |
