| Artikelnummer | TX08D13VM0AAA |
| varumärke | KOE |
| Storlek | 3.0 |
| Ansökan | MPH |
| Upplösning | 240×400 |
| Sammansättning | LCM |
| Ljusstyrka | 250 |
| CR | 300:1 |
| Färger | 65K/262K |
| Bakgrundsbelysning | WLED |
| Gränssnitt | CPU |
| panelmärke | HITACHI |
| panelmodell | TX08D13VM0AAA |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 3.0 inch |
| upplösning | 240(RGB)×400 , WQVGA |
| visningsläge | IPS, Normally Black, Transmissive |
| aktivt område | 38.88×64.8 mm |
| skissera | 45.6×76 mm |
| yta | |
| ljusstyrka | 250 cd/m² (Typ.) |
| Kontrastförhållande | 300:1 (Typ.) |
| visa färger | 65K/262K , CIE193160% |
| respons tid | 35 (Typ.)(Tr+Td) |
| betraktningsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| lamptyp | 1S4PWLEDWithout Driver |
| signalgränssnitt | CPU, 35 pins |
| inspänning | 2.8/2.8V (Typ.)(VCi/IOVCC) |
| Ansökan | MPH |
