| Artikelnummer | TT101WSQ-N10 |
| varumärke | BOE |
| Storlek | 10.1 |
| Ansökan | NBPC |
| Upplösning | 1024×600 |
| Sammansättning | CELL |
| Ljusstyrka | 0 |
| CR | 600:1 |
| Färger | 262K |
| Bakgrundsbelysning | No B/L |
| Gränssnitt | |
| panelmärke | BOE |
| panelmodell | TT101WSQ-N10 |
| paneltyp | a-Si TFT-LCD , CELL |
| panelstorlek | 10.1 inch |
| upplösning | 1024(RGB)×600 , WSVGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 222.72×125.28 mm |
| skissera | 230.4×134.2 mm |
| yta | |
| transmissivitet | 6.17% (Typ.)(with Polarizer) |
| Kontrastförhållande | 600:1 (Typ.) |
| visa färger | 262K (6-bit), CIE193155% |
| respons tid | 8 (Typ.)(Tr+Td) |
| betraktningsvinkel | 70/70/55/70 (Typ.)(CR≥10)(L/R/U/D) |
| Ansökan | NBPC |
