| Artikelnummer | T400XW01 V7 |
| varumärke | AUO |
| Storlek | 40 |
| Ansökan | LCTV |
| Upplösning | 1366×768 |
| Sammansättning | LCM |
| Ljusstyrka | 450 |
| CR | 3000:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | LVDS |
| panelmärke | AUO |
| panelmodell | T400XW01 V7 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 40 inch |
| upplösning | 1366(RGB)×768 , WXGA |
| visningsläge | AMVA3, Normally Black, Transmissive |
| aktivt område | 885.168×497.664 mm |
| skissera | 952×551 mm |
| yta | Antiglare (Haze 11%), Hard coating (3H) |
| ljusstyrka | 450 cd/m² (Typ.) |
| Kontrastförhållande | 3000:1 (Typ.) |
| visa färger | 16.7M (8-bit) |
| respons tid | 6.5 (Typ.)(G to G) |
| betraktningsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 14 pcsCCFLEmbedded (Balance board) |
| signalgränssnitt | LVDS (1 ch, 8-bit), 30 pins |
| inspänning | 12.0V (Typ.) |
| Ansökan | LCTV |
