| Artikelnummer | T315XW02 VK |
| varumärke | AUO |
| Storlek | 31.5 |
| Ansökan | LCTV |
| Upplösning | 1366×768 |
| Sammansättning | LCM |
| Ljusstyrka | 540 |
| CR | 2500:1 |
| Färger | 1.07B |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | LVDS |
| panelmärke | AUO |
| panelmodell | T315XW02 VK |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 31.5 inch |
| upplösning | 1366(RGB)×768 , WXGA |
| visningsläge | AMVA, Normally Black, Transmissive |
| aktivt område | 697.685×392.256 mm |
| skissera | 741×435 mm |
| yta | Antiglare (Haze 11%), Hard coating (3H) |
| ljusstyrka | 540 cd/m² (Typ.) |
| Kontrastförhållande | 2500:1 (Typ.) |
| visa färger | 1.07B (10-bit), CIE193188% |
| respons tid | 6.5 (Typ.)(G to G) |
| betraktningsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 16 pcsCCFLEmbedded (Inverter) |
| signalgränssnitt | LVDS (1 ch, 10-bit), 41 pins |
| inspänning | 12.0V (Typ.) |
| Ansökan | LCTV |
