| Artikelnummer | T-55692D070H-LW-A-AAN |
| varumärke | Kyocera |
| Storlek | 7.0 |
| Ansökan | IA |
| Upplösning | 800×480 |
| Sammansättning | LCM |
| Ljusstyrka | 1000 |
| CR | 1000:1 |
| Färger | 262K/16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | OPTREX |
| panelmodell | T-55692D070H-LW-A-AAN 1 Compatible model |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 7.0 inch |
| upplösning | 800(RGB)×480 , WVGA |
| visningsläge | IPS, Normally Black, Transmissive |
| aktivt område | 152.4×91.44 mm |
| skissera | 169.8×109.7×9.4 mm |
| yta | Clear, Hard coating (3H) |
| ljusstyrka | 1000 cd/m² (Typ.) |
| Kontrastförhållande | 1000:1 (Typ.) |
| visa färger | 262K/16.7M (6-bit / 8-bit), CIE193150% |
| respons tid | 12/12 (Typ.)(Tr/Td) |
| betraktningsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | WLEDEmbedded (LED Driver) |
| signalgränssnitt | LVDS (1 ch, 6/8-bit), 20 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | IA |
