| Artikelnummer | NL10276AC30-03 |
| varumärke | NLT |
| Storlek | 15.0 |
| Ansökan | DMPC |
| Upplösning | 1024×768 |
| Sammansättning | LCM |
| Ljusstyrka | 200 |
| CR | 200:1 |
| Färger | Full color |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | Analog |
| panelmärke | NEC |
| panelmodell | NL10276AC30-03 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 15.0 inch |
| upplösning | 1024(RGB)×768 , XGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 304.128×228.096 mm |
| skissera | 350×265×20.5 mm |
| yta | |
| ljusstyrka | 200 cd/m² (Typ.) |
| Kontrastförhållande | 200:1 (Typ.) |
| visa färger | Full color , CIE193142% |
| respons tid | 15/40 (Typ.)(Tr/Td) |
| betraktningsvinkel | 55/55/50/45 (Typ.)(CR≥10)(L/R/U/D) |
| lamptyp | 2 pcsCCFLEmbedded (Inverter) |
| signalgränssnitt | Analog RGB, 41 pins |
| inspänning | 12.0V (Typ.) |
| Ansökan | DMPC |
