| Artikelnummer | LTN170BT09-001 |
| varumärke | Samsung |
| Storlek | 17.0 |
| Ansökan | NBPC |
| Upplösning | 1440×900 |
| Sammansättning | LCM |
| Ljusstyrka | 200 |
| CR | 600:1 |
| Färger | 262K |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | LVDS |
| panelmärke | SAMSUNG |
| panelmodell | LTN170BT09-001 2 Compatible model |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 17.0 inch |
| upplösning | 1440(RGB)×900 , WXGA+ |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 367.2×229.5 mm |
| skissera | 382.2×244.5×7 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| yta | Antiglare (Haze 25%), Hard coating (3H) |
| ljusstyrka | 200 cd/m² (Typ.) |
| Kontrastförhållande | 600:1 (Typ.) |
| visa färger | 262K (6-bit), CIE193144% |
| respons tid | 16 (Typ.)(Tr+Td) |
| betraktningsvinkel | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 1 pcsCCFLWithout Driver |
| signalgränssnitt | LVDS (2 ch, 6-bit), 30 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | NBPC |
