| Artikelnummer | LTN156AT20-P01 |
| varumärke | Samsung |
| Storlek | 15.6 |
| Ansökan | NBPC |
| Upplösning | 1366×768 |
| Sammansättning | LCM |
| Ljusstyrka | 200 |
| CR | |
| Färger | 262K |
| Bakgrundsbelysning | WLED |
| Gränssnitt | |
| panelmärke | SAMSUNG |
| panelmodell | LTN156AT20-P01 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 15.6 inch |
| upplösning | 1366(RGB)×768 , WXGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 344.232×193.536 mm |
| form stil | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| yta | |
| ljusstyrka | 200 cd/m² (Typ.) |
| Kontrastförhållande | |
| visa färger | 262K (6-bit) |
| respons tid | |
| betraktningsvinkel | |
| frekvens | 60Hz |
| lamptyp | WLEDEmbedded (LED Driver) |
| Ansökan | NBPC |
