| Artikelnummer | LTN097XL01-A02 |
| varumärke | Samsung |
| Storlek | 9.7 |
| Ansökan | PAD |
| Upplösning | 1024×768 |
| Sammansättning | LCM |
| Ljusstyrka | 390 |
| CR | 900:1 |
| Färger | 262K |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | SAMSUNG |
| panelmodell | LTN097XL01-A02 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 9.7 inch |
| upplösning | 1024(RGB)×768 , XGA |
| visningsläge | PLS, Normally Black, Transmissive |
| aktivt område | 196.608×147.456 mm |
| yta | Glare (Haze 0%), Hard coating (3H) |
| ljusstyrka | 390 cd/m² (Typ.) |
| Kontrastförhållande | 900:1 (Typ.) |
| visa färger | 262K (6-bit), CIE193152% |
| respons tid | 30 (Typ.)(Tr+Td) |
| betraktningsvinkel | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | WLEDWithout Driver |
| signalgränssnitt | LVDS (1 ch, 6-bit), 30 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | PAD |
