| Artikelnummer | LSC550FN05 |
| varumärke | Samsung |
| Storlek | 55 |
| Ansökan | LCTV |
| Upplösning | 3840×2160 |
| Sammansättning | CELL |
| Ljusstyrka | 0 |
| CR | 4000:1 |
| Färger | 1.07B |
| Bakgrundsbelysning | No B/L |
| Gränssnitt | V-by-One |
| panelmärke | SAMSUNG |
| panelmodell | LSC550FN05 |
| paneltyp | a-Si TFT-LCD , CELL |
| panelstorlek | 55 inch |
| upplösning | 3840(RGB)×2160 , UHD |
| visningsläge | SVA, Normally Black, Transmissive |
| aktivt område | 1209.6×680.4 mm |
| skissera | 1223.6×697.1 mm |
| yta | Antiglare (Haze 2.3%), Hard coating (2H) |
| glasdjup | 0.50+0.50 mm |
| transmissivitet | 4.6% (Typ.)(with Polarizer) |
| Kontrastförhållande | 4000:1 (Typ.) |
| visa färger | 1.07B (8-bit + Dithering), CIE193168% |
| respons tid | 8 (Typ.)(G to G) |
| betraktningsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signalgränssnitt | V-by-One 8 lane, 51 pins |
| inspänning | 12.0V (Typ.) |
| Ansökan | LCTV |
