| Artikelnummer | LS024Q8DD92 |
| varumärke | SHARP |
| Storlek | 2.4 |
| Ansökan | |
| Upplösning | 240×320 |
| Sammansättning | CELL |
| Ljusstyrka | 0 |
| CR | 100:1 |
| Färger | 65K/262K |
| Bakgrundsbelysning | No B/L |
| Gränssnitt | TTL |
| panelmärke | SHARP |
| panelmodell | LS024Q8DD92 |
| paneltyp | CG-Silicon , CELL |
| panelstorlek | 2.4 inch |
| upplösning | 240(RGB)×320 , QVGA |
| visningsläge | TN, Normally White, Transflective |
| aktivt område | 36.72×48.96 mm |
| skissera | 41.2×58 mm |
| yta | Hard coating (3H) |
| glasdjup | 0.50+0.50 mm |
| Kontrastförhållande | 100:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| visa färger | 65K/262K |
| respons tid | 13/35 (Typ.)(Tr/Td) |
| betraktningsvinkel | 45/45/35/45 (Typ.)(CR≥3)(L/R/U/D) |
| drivrutin ic | Built-in uPD161831 |
| signalgränssnitt | Parallel RGB (1 ch, 6-bit), 60 pins |
| inspänning | 3.0/3.0V (Typ.)(VCC/VDC) |
| A024CN02 VJ | AUO | 2.4 | 480×234 |
| DMC-16105NY-LY-ANN | Kyocera | 2.4 | 16×1 |
| LS024J3LX01 | SHARP | 2.4 | 320×480 |
| LS024Q3UX05 | SHARP | 2.4 | 240×320 |
| LS024Q3UX12(G) | SHARP | 2.4 | 320×240 |
| LS024Q8DD92 | SHARP | 2.4 | 240×320 |
| LS024Q8UC02 | SHARP | 2.4 | 240×320 |
| RGS24128022YR000 | RiTdisplay | 2.4 | 128×22 |
| TM024HBZ26 | Tianma | 2.4 | 240×320 |
| TP241MC01G | Neoview Kolon | 2.4 | 240×320 |
| LTA065A040F | TOSHIBA | 6.5 | 640×480 |
| LTD121KM7K | TOSHIBA | 12.1 | 1400×1050 |
| LTM12C268F | TOSHIBA | 12.1 | 800×600 |
| OEL9M5001-G-E | Other | 2.7 | 128×64 |
| OEL9M5003-B-E | Other | 2.7 | 128×64 |
| OEL9M5003-G-E | Other | 2.7 | 128×64 |
| PD104VT3H1 | E Ink | 10.4 | 640×480 |
| SC2002A | Other | 2.9 | 20×2 |
| TFD50W52MS3 | TOSHIBA | 5.0 | |
| UG-9616TSWCG02 | WiseChip | 0.69 | 96×16 |
