| Artikelnummer | LQ10DH11 |
| varumärke | SHARP |
| Storlek | 10.4 |
| Ansökan | IA |
| Upplösning | 640×480 |
| Sammansättning | LCM |
| Ljusstyrka | 80 |
| CR | 60:1 |
| Färger | 512 |
| Bakgrundsbelysning | HCFL |
| Gränssnitt | TTL |
| panelmärke | SHARP |
| panelmodell | LQ10DH11 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 10.4 inch |
| upplösning | 640(RGB)×480 , VGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 211.2×158.4 mm |
| skissera | 283×217 mm |
| yta | Antiglare, Hard coating (2H) |
| ljusstyrka | 80 cd/m² (Typ.) |
| Kontrastförhållande | 60:1 (Min.) |
| visa färger | 512 (3-bit) |
| respons tid | 30/50 (Typ.)(Tr/Td) |
| betraktningsvinkel | 45/45/10/30 (Typ.)(CR≥10)(L/R/U/D) |
| lamptyp | 2 pcsHCFLWithout Driver |
| signalgränssnitt | Parallel RGB (1 ch, 3-bit), 22 pins |
| inspänning | 5.0/12.0V (Typ.)(VCC/VDD) |
| Ansökan | IA |
