| Artikelnummer | LQ055T3SX04 |
| varumärke | SHARP |
| Storlek | 5.5 |
| Ansökan | MPH |
| Upplösning | 1080×1920 |
| Sammansättning | CELL |
| Ljusstyrka | 0 |
| CR | 1000:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | No B/L |
| Gränssnitt | |
| panelmärke | SHARP |
| panelmodell | LQ055T3SX04 |
| paneltyp | IGZO TFT-LCD , CELL |
| panelstorlek | 5.5 inch |
| upplösning | 1080(RGB)×1920 , FHD |
| visningsläge | New Mode2, Normally Black, Transmissive |
| aktivt område | 68.04×120.96 mm |
| skissera | 70.84×128.16 mm |
| yta | |
| glasdjup | 0.20+0.20 mm |
| transmissivitet | 4.2% (Typ.)(with Polarizer) |
| Kontrastförhållande | 1000:1 (Typ.) |
| visa färger | 16.7M (8-bit), CIE193170% |
| respons tid | 35 (Max.)(Tr+Td) |
| betraktningsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| drivrutin ic | COG Built-in NT35532 |
| Ansökan | MPH |
