| Artikelnummer | LP154WU1-TLB1 |
| varumärke | LG Display |
| Storlek | 15.4 |
| Ansökan | NBPC |
| Upplösning | 1920×1200 |
| Sammansättning | LCM |
| Ljusstyrka | 175 |
| CR | 300:1 |
| Färger | 262K |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | LVDS |
| panelmärke | LG.Philips LCD |
| panelmodell | LP154WU1-TLB1 4 Compatible model |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 15.4 inch |
| upplösning | 1920(RGB)×1200 , WUXGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 331.2×207 mm |
| skissera | 344×222×6.5 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| yta | Antiglare, Hard coating (2H), Antireflection |
| ljusstyrka | 175 cd/m² (Typ.) |
| Kontrastförhållande | 300:1 (Typ.) |
| visa färger | 262K (6-bit), CIE193145% |
| respons tid | 16 (Typ.)(Tr+Td) |
| betraktningsvinkel | 65/65/50/50 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 1 pcsCCFLWithout Driver |
| signalgränssnitt | LVDS (2 ch, 6-bit), 30 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | NBPC |
| LP154W01-A3 | LG Display | 15.4 | 1280×800 |
| LP154W01-TLE5 | LG Display | 15.4 | 1280×800 |
| LP154W01-TLF1 | LG Display | 15.4 | 1280×800 |
| LP154WE2-TLA3 | LG Display | 15.4 | 1680×1050 |
| LP154WP2-TLA1 | LG Display | 15.4 | 1440×900 |
| LP154WP2-TLC2 | LG Display | 15.4 | 1440×900 |
| LP154WP4-TLA1 | LG Display | 15.4 | 1440×900 |
| LP154WT1-SJA1 | LG Display | 15.4 | 2880×1800 |
| LP154WU1-TLA2 | LG Display | 15.4 | 1920×1200 |
| LP154WU1-TLC1 | LG Display | 15.4 | 1920×1200 |
| B133XW07 V0 | AUO | 13.3 | 1366×768 |
| B140HAN01.0 | AUO | 14.0 | 1920×1080 |
| LP133X3-A | LG Display | 13.3 | 1024×768 |
| LP171WP7-TLB1 | LG Display | 17.1 | 1440×900 |
| LTM08C355S | TOSHIBA | 8.4 | 800×600 |
| LTM09C362Z | TOSHIBA | 8.9 | 1024×600 |
| LTN133AT23-X01 | Samsung | 13.3 | 1366×768 |
| LTN156KT06-801 | Samsung | 15.6 | 1600×900 |
| M116NWR1 R7 | IVO | 11.6 | 1366×768 |
| NL8060BC31-13A | NLT | 12.1 | 800×600 |
