| Artikelnummer | LM240WU4-SLB1 |
| varumärke | LG Display |
| Storlek | 24.0 |
| Ansökan | DMPC |
| Upplösning | 1920×1200 |
| Sammansättning | LCM |
| Ljusstyrka | 400 |
| CR | 1000:1 |
| Färger | 1.07B |
| Bakgrundsbelysning | CCFL |
| Gränssnitt | LVDS |
| panelmärke | LG Display |
| panelmodell | LM240WU4-SLB1 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 24.0 inch |
| upplösning | 1920(RGB)×1200 , WUXGA |
| visningsläge | S-IPS, Normally Black, Transmissive |
| aktivt område | 518.4×324 mm |
| skissera | 546.4×352×40.8 mm |
| yta | Antiglare, Hard coating (3H) |
| ljusstyrka | 400 cd/m² (Typ.) |
| Kontrastförhållande | 1000:1 (Typ.) |
| visa färger | 1.07B (8-bit + Hi-FRC), CIE1931102% |
| respons tid | 6/7 (Typ.)(Tr/Td); 6 (Typ.)(G to G) |
| betraktningsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 7 pcsCCFLEmbedded (Inverter) |
| signalgränssnitt | LVDS (2 ch, 10-bit), 51 pins |
| inspänning | 12.0V (Typ.) |
| Ansökan | DMPC |
