| Artikelnummer | LM185TT1A |
| varumärke | PANDA |
| Storlek | 18.5 |
| Ansökan | DMPC |
| Upplösning | 1366×768 |
| Sammansättning | LCM |
| Ljusstyrka | 250 |
| CR | 1000:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | PANDA |
| panelmodell | LM185TT1A |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 18.5 inch |
| upplösning | 1366(RGB)×768 , WXGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 409.8×230.4 mm |
| skissera | 430.37×254.6×11 mm |
| yta | Antiglare, Hard coating (3H) |
| ljusstyrka | 250 cd/m² (Typ.) |
| Kontrastförhållande | 1000:1 (Typ.) |
| visa färger | 16.7M (6-bit + Hi-FRC), CIE193172% |
| respons tid | 5 (Typ.)(Tr+Td) |
| betraktningsvinkel | 85/85/80/80 (Typ.)(CR＞10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 10S4PWLEDWithout Driver |
| signalgränssnitt | LVDS (1 ch, 8-bit), 30 pins |
| inspänning | 5.0V (Typ.) |
| Ansökan | DMPC |
| LM185TT1A | PANDA | 18.5 | 1366×768 |
| LM185TT4A | PANDA | 18.5 | 1366×768 |
| LM185WH1-TLA1 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLC5 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLD1 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLF1 | LG Display | 18.5 | 1366×768 |
| LM185WH2-T2BB | LG Display | 18.5 | 1366×768 |
| LM185WH2-TLA1 | LG Display | 18.5 | 1366×768 |
| LM185WH2-TLE2 | LG Display | 18.5 | 1366×768 |
| LM18WGSBZ05 | SHARP | 1.8 | 120×160 |
| HM215WU3-100 | BOE | 21.5 | 1920×1080 |
| HSD170MGW1-A00 | HannStar | 17.0 | 1440×900 |
| LM190WX1-TLL1 | LG Display | 19.0 | 1440×900 |
| LM215WF4-TLE1 | LG Display | 21.5 | 1920×1080 |
| LM250WF3-TLA1 | LG Display | 25.0 | 1920×1080 |
| LTM170E6-L03 | Samsung | 17.0 | 1280×1024 |
| LTM240CT06 | Samsung | 24.0 | 1920×1200 |
| M240J1-L03 | Innolux | 24.0 | 1920×1200 |
| MT190AW02 V.V | Innolux | 19.0 | 1440×900 |
| MT190EN02 V.W | Innolux | 19.0 | 1280×1024 |
