| Artikelnummer | LH300WQ1-ED01 |
| varumärke | LG Display |
| Storlek | 3.0 |
| Ansökan | MPH |
| Upplösning | 240×400 |
| Sammansättning | OLED |
| Ljusstyrka | 210 |
| CR | 2000:1 |
| Färger | 65K/262K |
| Bakgrundsbelysning | self |
| Gränssnitt | CPU/RGB/SPI |
| panelmärke | LG Display |
| panelmodell | LH300WQ1-ED01 |
| paneltyp | AM-OLED , OLED |
| panelstorlek | 3.0 inch |
| upplösning | 240(RGB)×400 , WQVGA |
| aktivt område | 38.88×64.8 mm |
| skissera | 44×74.6 mm |
| yta | Hard coating |
| ljusstyrka | 210 cd/m² (Typ.) |
| Kontrastförhållande | 2000 : 1 (Min.) |
| visa färger | 65K/262K , CIE193185% |
| betraktningsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signalgränssnitt | 8/9/16/18-bit 6800/8080 parallel, 6/16/18-bit RGB, SPI, 40 pins |
| inspänning | 2.8/2.8/3.7V (Typ.)(VDD/VCC/VBATT) |
| Ansökan | MPH |
