| Artikelnummer | LD470DXS-SCB1 |
| varumärke | LG Display |
| Storlek | 47 |
| Ansökan | DID |
| Upplösning | 1366×768 |
| Sammansättning | LCM |
| Ljusstyrka | 500 |
| CR | 1400:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | LG Display |
| panelmodell | LD470DXS-SCB1 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 47 inch |
| upplösning | 1366(RGB)×768 , WXGA |
| visningsläge | S-IPS, Normally Black, Transmissive |
| aktivt område | 1039.87×584.64 mm |
| skissera | 1046.8×591.6×50.5 mm, Videowall Seam 6.9 mm |
| yta | Antiglare (Haze 10%), Hard coating (3H) |
| ljusstyrka | 500 cd/m² (Typ.) |
| Kontrastförhållande | 1400:1 (Typ.) |
| visa färger | 16.7M (8-bit), CIE193172% |
| respons tid | 12 (Typ.)(G to G) |
| betraktningsvinkel | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | WLEDEmbedded (LED Driver) |
| signalgränssnitt | LVDS (1 ch, 8-bit), 30 pins |
| inspänning | 12.0V (Typ.) |
| Ansökan | DID |
