| Artikelnummer | LAM170M023A |
| varumärke | JDI |
| Storlek | 17.0 |
| Ansökan | MD |
| Upplösning | 1280×1024 |
| Sammansättning | LCM |
| Ljusstyrka | 240 |
| CR | 900:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | JDI |
| panelmodell | LAM170M023A |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 17.0 inch |
| upplösning | 1280(RGB)×1024 , SXGA |
| visningsläge | IPS, Normally Black, Transmissive |
| aktivt område | 337.92×270.336 mm |
| skissera | 368×306×20.4 mm |
| yta | Antiglare, Hard coating (2H) |
| ljusstyrka | 240 cd/m² (Typ.) |
| Kontrastförhållande | 900:1 (Typ.) |
| visa färger | 16.7M (8-bit), CIE193174% |
| respons tid | 10/12 (Typ.)(Tr/Td) |
| betraktningsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 3 stringsWLEDEmbedded (LED Driver) |
| signalgränssnitt | LVDS (2 ch, 8-bit), 30 pins |
| inspänning | 5.0V (Typ.) |
| Ansökan | MD |
| G170ETN02.0 | AUO | 17.0 | 1280×1024 |
| L170E3 EC-5 | AUO | 17.0 | 1280×1024 |
| LAM170M023A | JDI | 17.0 | 1280×1024 |
| LM170E03-TLJ6 | LG Display | 17.0 | 1280×1024 |
| LTM170EU-L31 | Samsung | 17.0 | 1280×1024 |
| LTN170BT11-D03 | Samsung | 17.0 | 1440×900 |
| LTN170U1-L02 | Samsung | 17.0 | 1920×1200 |
| M170EG01 V5 | AUO | 17.0 | 1280×1024 |
| M170EG01 VH | AUO | 17.0 | 1280×1024 |
| M170XW01 V3 | AUO | 17.0 | 1280×768 |
| G213QAN01.0 | AUO | 21.3 | 2048×1536 |
| HV208QX1-100 | HYDIS | 20.8 | 2048×1536 |
| LAM170M023A | JDI | 17.0 | 1280×1024 |
| LB190E01-SL01 | LG Display | 19.0 | 1280×1024 |
| NL128102BM29-05A | NLT | 19.0 | 1280×1024 |
| NL160120BM27-03A | NLT | 21.3 | 1600×1200 |
| NL204153AC21-09 | NLT | 21.3 | 2048×1536 |
| NL204153BM21-05A | NLT | 21.3 | 2048×1536 |
| R300M1-L01 | Innolux | 30.0 | 4096×2560 |
| VVX21F136J00 | Panasonic | 21.3 | 1600×1200 |
