| Artikelnummer | HV460WU2-202 |
| varumärke | BOE |
| Storlek | 46 |
| Ansökan | LCTV |
| Upplösning | 1920×1080 |
| Sammansättning | CELL |
| Ljusstyrka | 0 |
| CR | 1200:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | No B/L |
| Gränssnitt | LVDS |
| panelmärke | BOE |
| panelmodell | HV460WU2-202 |
| paneltyp | a-Si TFT-LCD , CELL |
| panelstorlek | 46 inch |
| upplösning | 1920(RGB)×1080 , FHD |
| visningsläge | ADS, Normally Black, Transmissive |
| aktivt område | 1018.08×572.67 mm |
| skissera | 1039.1×590.7 mm |
| yta | Antiglare (Haze 10%), Hard coating (3H) |
| glasdjup | 0.70+0.70 mm |
| transmissivitet | 6.2% (Typ.)(with Polarizer) |
| Kontrastförhållande | 1200:1 (Typ.) |
| visa färger | 16.7M (8-bit), CIE193172% |
| respons tid | 8 (Typ.)(G to G) |
| betraktningsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signalgränssnitt | LVDS (2 ch, 8-bit), 51 pins |
| inspänning | 12.0V (Typ.) |
| Ansökan | LCTV |
| HV460WU2-202 | BOE | 46 | 1920×1080 |
| HV460WUC-200 | BOE | 46 | 1920×1080 |
| LTA460HN01-W | Samsung | 46 | 1920×1080 |
| LTA460WT-L14 | Samsung | 46 | 1366×768 |
| LTI460AP01 | Samsung | 46 | 1366×768 |
| LTI460HN05 | Samsung | 46 | 1920×1080 |
| LTI460HN09 | Samsung | 46 | 1920×1080 |
| LTY460HB01 | Samsung | 46 | 1920×1080 |
| T460HVN08.2 CELL | AUO | 46 | 1920×1080 |
| T460HW08 V0 | AUO | 46 | 1920×1080 |
| LC171W03-A4K5 | LG Display | 17.1 | 1280×768 |
| LC320WXN-SCA1 | LG Display | 31.5 | 1366×768 |
| LC420DUH-FGA2 | LG Display | 42 | 1920×1080 |
| LTA260AP08 | Samsung | 26.0 | 1366×768 |
| LTA320WT-L16 | Samsung | 31.5 | 1366×768 |
| MT4601B02-1 | CSOT | 46 | 1920×1080 |
| T470HVN01.0 | AUO | 47 | 1920×1080 |
| V236H1-L01 | Innolux | 23.6 | 1920×1080 |
| V420H1-LH5 | Innolux | 42 | 1920×1080 |
| V580DK1-QS2 | Innolux | 58 | 3840×2160 |
