| Artikelnummer | HT260WX2-101 |
| varumärke | BOE |
| Storlek | 26.0 |
| Ansökan | LCTV |
| Upplösning | 1366×768 |
| Sammansättning | CELL |
| Ljusstyrka | 0 |
| CR | 800:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | No B/L |
| Gränssnitt | LVDS |
| panelmärke | BOE |
| panelmodell | HT260WX2-101 |
| paneltyp | a-Si TFT-LCD , CELL |
| panelstorlek | 26.0 inch |
| upplösning | 1366(RGB)×768 , WXGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 575.769×323.712 mm |
| skissera | 592×339.8 mm |
| yta | Antiglare (Haze 25%), Hard coating (3H) |
| glasdjup | 0.70+0.70 mm |
| transmissivitet | 7.05% (Typ.)(with Polarizer) |
| Kontrastförhållande | 800:1 (Typ.) |
| visa färger | 16.7M (6-bit + Hi-FRC), CIE193172% |
| respons tid | 5 (Typ.)(G to G) |
| betraktningsvinkel | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signalgränssnitt | LVDS (1 ch, 8-bit), 30 pins |
| inspänning | 12.0V (Typ.) |
| Ansökan | LCTV |
