| Artikelnummer | HSD140PNW1-B00 |
| varumärke | HannStar |
| Storlek | 14.0 |
| Ansökan | NBPC |
| Upplösning | 1600×900 |
| Sammansättning | LCM |
| Ljusstyrka | 250 |
| CR | 300:1 |
| Färger | 262K |
| Bakgrundsbelysning | WLED |
| Gränssnitt | eDP |
| panelmärke | HannStar |
| panelmodell | HSD140PNW1-B00 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 14.0 inch |
| upplösning | 1600(RGB)×900 , HD+ |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 309.6×174.15 mm |
| skissera | 320.4×205.1×3 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| yta | Antiglare, Hard coating (3H) |
| ljusstyrka | 250 cd/m² (Typ.) |
| Kontrastförhållande | 300:1 (Typ.) |
| visa färger | 262K (6-bit), CIE193160% |
| respons tid | 4/12 (Typ.)(Tr/Td) |
| betraktningsvinkel | 40/40/15/30 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | WLEDEmbedded (LED Driver) |
| signalgränssnitt | eDP (2 Lanes), 30 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | NBPC |
