| Artikelnummer | HSD060FMW1-C00 |
| varumärke | HannStar |
| Storlek | 6.0 |
| Ansökan | MPH |
| Upplösning | 540×960 |
| Sammansättning | CELL |
| Ljusstyrka | 0 |
| CR | 800:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | No B/L |
| Gränssnitt | MIPI |
| panelmärke | HannStar |
| panelmodell | HSD060FMW1-C00 1 Compatible model |
| paneltyp | a-Si TFT-LCD , CELL |
| panelstorlek | 6.0 inch |
| upplösning | 540(RGB)×960 , qHD |
| visningsläge | IPS Pro, Normally Black, Transmissive |
| aktivt område | 73.99×131.53 mm |
| skissera | 76.58×139.02×0.5 mm |
| yta | Without Polarizer |
| glasdjup | 0.25+0.25 mm |
| transmissivitet | 11.52% (Typ.)(without Polarizer) |
| Kontrastförhållande | 800:1 (Typ.) |
| visa färger | 16.7M (8-bit), CIE193170% |
| respons tid | 30 (Typ.)(Tr+Td) |
| betraktningsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| drivrutin ic | Suggest NT35516, NT35517, HX8389-B, RM68190, OTM9608A, OTM9605A |
| signalgränssnitt | MIPI (2 data lanes) |
| Ansökan | MPH |
| A060SE02 V2 | AUO | 6.0 | 800×600 |
| BA060WV1-100 CELL | BOE | 6.0 | 480×854 |
| ED060SC4 | E Ink | 6.0 | 800×600 |
| ED060SCC | E Ink | 6.0 | 600×800 |
| ED060SCF | E Ink | 6.0 | 600×800 |
| HSD060FMW1-C00 | HannStar | 6.0 | 540×960 |
| LQ060B3DW01 | SHARP | 6.0 | 768×128 |
| LS060S2UD01 | SHARP | 6.0 | 600×800 |
| TFD60W12 | TOSHIBA | 6.0 | 320×234 |
| TM060RDH03 | Tianma | 6.0 | 800×480 |
| AMS320FS03 | Samsung | 3.2 | 320×480 |
| H347QN02 V0 | AUO | 3.5 | 320×480 |
| H446TAN01.1 | AUO | 4.5 | 720×1280 |
| H497TLB01 | AUO | 5.0 | 720×1280 |
| LH400WS2-SD03 | LG Display | 4.0 | 640×1136 |
| LS028B7UX01 | SHARP | 2.8 | 240×400 |
| LS036Y1LX03 | SHARP | 3.6 | 480×800 |
| LS037V7DD06R | SHARP | 3.7 | 480×640 |
| LS055T1SX01 | SHARP | 5.5 | 1080×1920 |
| TD028STEB2 | TPO | 2.8 | 240×320 |
