| Artikelnummer | HE070IA-04M |
| varumärke | Innolux |
| Storlek | 7.0 |
| Ansökan | PAD |
| Upplösning | 800×1280 |
| Sammansättning | CELL |
| Ljusstyrka | 0 |
| CR | 800:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | No B/L |
| Gränssnitt | MIPI |
| panelmärke | INNOLUX |
| panelmodell | HE070IA-04M |
| paneltyp | a-Si TFT-LCD , CELL |
| panelstorlek | 7.0 inch |
| upplösning | 800(RGB)×1280 , WXGA |
| visningsläge | IPS, Normally Black, Transmissive |
| aktivt område | 94.2×150.72 mm |
| skissera | 101.5×159.52×0.77 mm |
| yta | Hard coating |
| glasdjup | 0.25+0.25 mm |
| transmissivitet | 3.6% (Typ.)(with Polarizer) |
| Kontrastförhållande | 800:1 (Typ.) |
| visa färger | 16.7M (8-bit), CIE193160% |
| respons tid | 15/25 (Typ.)(Tr/Td) |
| betraktningsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signalgränssnitt | MIPI (4 data lanes), 40 pins |
| inspänning | 3.3/8.8/22.0/-7.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| Ansökan | PAD |
