| Artikelnummer | H495TAN01.1 |
| varumärke | AUO |
| Storlek | 5.0 |
| Ansökan | MPH |
| Upplösning | 720×1280 |
| Sammansättning | CELL |
| Ljusstyrka | 0 |
| CR | 900:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | No B/L |
| Gränssnitt | |
| panelmärke | AUO |
| panelmodell | H495TAN01.1 |
| paneltyp | a-Si TFT-LCD , CELL |
| panelstorlek | 5.0 inch |
| upplösning | 720(RGB)×1280 , WXGA |
| visningsläge | AHVA, Normally Black, Transmissive |
| aktivt område | 61.688×109.632 mm |
| skissera | 63.67×115.85×0.3 mm |
| yta | |
| glasdjup | 0.15+0.15 mm |
| transmissivitet | 3.26% (Typ.)(with Polarizer) |
| Kontrastförhållande | 900:1 (Typ.) |
| visa färger | 16.7M (8-bit), CIE193194% |
| respons tid | 35 (Max.)(Tr+Td) |
| betraktningsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| drivrutin ic | COG Suggest HX8394-D21, N35521-DPAU, N35521S-DP8AU, OTM1284A-C6, OTM1287A-C8, R61318, RM68200 |
| Ansökan | MPH |
