| Artikelnummer | H320QN01 V2 |
| varumärke | AUO |
| Storlek | 3.2 |
| Ansökan | MPH |
| Upplösning | 320×480 |
| Sammansättning | LCM |
| Ljusstyrka | 400 |
| CR | 800:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | MDDI/MIPI |
| panelmärke | AUO |
| panelmodell | H320QN01 V2 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 3.2 inch |
| upplösning | 320(RGB)×480 , HVGA |
| visningsläge | AMVA, Normally Black, Transmissive |
| aktivt område | 45.12×67.68 mm |
| skissera | 50.6×78.9×2.18 mm |
| yta | |
| ljusstyrka | 400 cd/m² (Typ.) |
| Kontrastförhållande | 800:1 (Typ.) |
| visa färger | 16.7M (8-bit), CIE193167% |
| respons tid | 35 (Max.)(Tr+Td) |
| betraktningsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 6S1PWLEDWithout Driver |
| signalgränssnitt | MDDI/MIPI, 23 pins |
| inspänning | 1.8/2.85V (IOVDD/AVDD) |
| Ansökan | MPH |
