| Artikelnummer | GPM782A0 |
| varumärke | Giantplus |
| Storlek | 3.5 |
| Ansökan | PND |
| Upplösning | 320×240 |
| Sammansättning | LCM |
| Ljusstyrka | 300 |
| CR | 350:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | TTL |
| panelmärke | Giantplus |
| panelmodell | GPM782A0 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 3.5 inch |
| upplösning | 320(RGB)×240 , QVGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 70.08×52.56 mm |
| skissera | 76.9×63.9 mm |
| yta | |
| ljusstyrka | 300 cd/m² (Typ.) |
| Kontrastförhållande | 350:1 (Typ.) |
| visa färger | 16.7M (8-bit) |
| respons tid | 25 (Typ.)(Tr+Td) |
| betraktningsvinkel | 60/60/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 6S1PWLEDWithout Driver |
| signalgränssnitt | Parallel RGB (1 ch, 8-bit) + SPI, 54 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | PND |
| ACX502BMU-7 | SONY | 3.5 | 240×320 |
| AM-320480-035BT | Other | 3.5 | 320×480 |
| DLC0350TZG | Other | 3.5 | 240×320 |
| EL160.80.50 ALU | PLANAR | 3.5 | 160×80 |
| GPM782A0 | Giantplus | 3.5 | 320×240 |
| LH350WS1-SD02 | LG Display | 3.5 | 640×960 |
| LMS350DF03 | Samsung | 3.5 | 320×480 |
| LQ035Q2DD56 | SHARP | 3.5 | 320×240 |
| LTM035A776C | TOSHIBA | 3.5 | 240×320 |
| NL2432DR22-02B | NLT | 3.5 | 240×320 |
| A043FW02 V0 | AUO | 4.3 | 480×272 |
| AT043TN25 V.1 | Innolux | 4.3 | 480×272 |
| HSD043I9W1-A00 | HannStar | 4.3 | 480×272 |
| LB050WQ2-TD03 | LG Display | 5.0 | 480×272 |
| LQ035Q1DG04 | SHARP | 3.5 | 320×240 |
| LQ043T3DX0G | SHARP | 4.3 | 480×272 |
| LTE400WQ-E01 | Samsung | 4.0 | 480×272 |
| LTP400WQ-F01 | Samsung | 4.0 | 480×272 |
| PT035TN01 V.6 | Innolux | 3.5 | 320×240 |
| PW035XS1 | E Ink | 3.5 | 320×234 |
