| Artikelnummer | G104XVN01.0 |
| varumärke | AUO |
| Storlek | 10.4 |
| Ansökan | IA |
| Upplösning | 1024×768 |
| Sammansättning | LCM |
| Ljusstyrka | 470 |
| CR | 3000:1 |
| Färger | 262K/16.2M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | AUO |
| panelmodell | G104XVN01.0 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 10.4 inch |
| upplösning | 1024(RGB)×768 , XGA |
| visningsläge | PSA, Normally Black, Transmissive |
| aktivt område | 210.4×157.8 mm |
| skissera | 238.6×175.8×7 mm |
| yta | Antiglare, Hard coating (3H) |
| ljusstyrka | 470 cd/m² (Typ.) |
| Kontrastförhållande | 3000:1 (Typ.) |
| visa färger | 262K/16.2M (6-bit / 6-bit + FRC), CIE193160% |
| respons tid | 20/10 (Typ.)(Tr/Td) |
| betraktningsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 2 stringsWLEDEmbedded (LED Driver) |
| signalgränssnitt | LVDS (1 ch, 6/8-bit), 30 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | IA |
