| Artikelnummer | DLC0500HZG-T-8 |
| varumärke | Other |
| Storlek | 5.0 |
| Ansökan | PND |
| Upplösning | 800×480 |
| Sammansättning | LCM |
| Ljusstyrka | 640 |
| CR | 500:1 |
| Färger | 16.7M |
| Bakgrundsbelysning | WLED |
| Gränssnitt | TTL |
| panelmärke | DLC |
| panelmodell | DLC0500HZG-T-8 |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 5.0 inch |
| upplösning | 800(RGB)×480 , WVGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 108×64.8 mm |
| skissera | 120.7×75.8×4.5 mm |
| yta | Antiglare, Hard coating (3H) |
| ljusstyrka | 640 cd/m² (Typ.) |
| Kontrastförhållande | 500:1 (Typ.) |
| visa färger | 16.7M (8-bit), CIE193150% |
| respons tid | 20 (Typ.)(Tr+Td) |
| betraktningsvinkel | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 10S2PWLEDWithout Driver |
| signalgränssnitt | Parallel RGB (1 ch, 8-bit), 40 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | PND |
