| Artikelnummer | DLC0350SZG |
| varumärke | Other |
| Storlek | 3.5 |
| Ansökan | MPH |
| Upplösning | 480×640 |
| Sammansättning | LCM |
| Ljusstyrka | 120 |
| CR | 500:1 |
| Färger | 262K |
| Bakgrundsbelysning | WLED |
| Gränssnitt | TTL |
| panelmärke | DLC |
| panelmodell | DLC0350SZG |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 3.5 inch |
| upplösning | 480(RGB)×640 , VGA |
| visningsläge | Normally Black, Transflective |
| aktivt område | 53.57×71.42 mm |
| skissera | 64×85×5.2 mm |
| yta | |
| ljusstyrka | 120 cd/m² (Typ.) |
| Kontrastförhållande | 500:1 (Typ.)(Transmissive)5:1 (Typ.)(Reflective) |
| visa färger | 262K (6-bit), CIE193155% |
| respons tid | 30 (Typ.)(Tr+Td) |
| betraktningsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 6S1PWLEDWithout Driver |
| signalgränssnitt | Parallel RGB (1 ch, 6-bit), 40 pins |
| inspänning | 2.8/2.8V (Typ.)(IOVCC/VCC) |
