| Artikelnummer | CLAA141WB11 |
| varumärke | CPT |
| Storlek | 14.1 |
| Ansökan | NBPC |
| Upplösning | 1280×800 |
| Sammansättning | LCM |
| Ljusstyrka | 220 |
| CR | 300:1 |
| Färger | 262K |
| Bakgrundsbelysning | WLED |
| Gränssnitt | LVDS |
| panelmärke | CPT |
| panelmodell | CLAA141WB11 2 Compatible model |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 14.1 inch |
| upplösning | 1280(RGB)×800 , WXGA |
| visningsläge | TN, Normally White, Transmissive |
| aktivt område | 303.74×189.84 mm |
| skissera | 319.5×205.5×5.5 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| yta | Antiglare, Hard coating (3H) |
| ljusstyrka | 220 cd/m² (Typ.) |
| Kontrastförhållande | 300:1 (Min.) |
| visa färger | 262K (6-bit), CIE193145% |
| respons tid | 4/8 (Typ.)(Tr/Td) |
| betraktningsvinkel | 40/40/15/30 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lamptyp | 8S6PWLEDWithout Driver |
| signalgränssnitt | LVDS (1 ch, 6-bit), 30 pins |
| inspänning | 3.3V (Typ.) |
| Ansökan | NBPC |
| CLAA101NB03A | CPT | 10.1 | 1024×600 |
| CLAA101ND02CW | CPT | 10.1 | 1024×600 |
| CLAA101WH12 LE | CPT | 10.1 | 1280×800 |
| CLAA102NA1BCN | CPT | 10.2 | 1024×600 |
| CLAA102NA2CCN | CPT | 10.2 | 1024×600 |
| CLAA133WB01A | CPT | 13.3 | 1366×768 |
| CLAA141WB11 | CPT | 14.1 | 1280×800 |
| CLAA154WB04A | CPT | 15.4 | 1280×800 |
| CLAA154WB08AN | CPT | 15.4 | 1280×800 |
| CLAA154WB09A | CPT | 15.4 | 1280×800 |
| B133XW01 V1 | AUO | 13.3 | 1366×768 |
| B156HTB01.0 | AUO | 15.6 | 1920×1080 |
| B156HW01 V0 | AUO | 15.6 | 1920×1080 |
| HV150UX1-100 | HYDIS | 15.0 | 1600×1200 |
| LP156WH3-TLL1 | LG Display | 15.6 | 1366×768 |
| LT121DEVQB00 | TOSHIBA | 12.1 | 1280×800 |
| LTD121KX5V | TOSHIBA | 12.1 | 1280×800 |
| LTN140AT19-201 | Samsung | 14.0 | 1366×768 |
| LTN150PF-L04 | Samsung | 15.0 | 1400×1050 |
| LTN184KT01-F01 | Samsung | 18.4 | 1680×945 |
