| Artikelnummer | 35HVE1H |
| varumärke | SII |
| Storlek | 3.5 |
| Ansökan | HHP |
| Upplösning | 320×480 |
| Sammansättning | LCM |
| Ljusstyrka | 350 |
| CR | 600:1 |
| Färger | 262K |
| Bakgrundsbelysning | WLED |
| Gränssnitt | CPU |
| panelmärke | SII |
| panelmodell | 35HVE1H |
| paneltyp | a-Si TFT-LCD , LCM |
| panelstorlek | 3.5 inch |
| upplösning | 320(RGB)×480 , HVGA |
| visningsläge | E-mode, Normally White, Transmissive |
| aktivt område | 48.96×73.44 mm |
| skissera | 54.96×85.94×2.3 mm |
| yta | Clear, Hard coating |
| ljusstyrka | 350 cd/m² (Typ.) |
| Kontrastförhållande | 600:1 (Typ.) |
| visa färger | 262K (6-bit), CIE193160% |
| respons tid | 30 (Typ.)(Tr+Td) |
| betraktningsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| lamptyp | 1S5PWLED |
| signalgränssnitt | CPU, 45 pins |
| Ansökan | HHP |
